The MS0202-19.32V302A-(302AH1P6S) has a standard capacity of 302Ah and a standard voltage of 19.32V, making it ideal for applications that require large amounts of power, such as electric vehicles and energy storage systems. And its internal intelligent monitoring system ensures stable and safe operation, alerting you in the event of a malfunction.
| Items | EP-LFP302Ah STANDARD MODULE | Note | |
| MS0202-19.32V302A | |||
| 302Ah1P6S | |||
| Nominal voltage(V) | 19.32 | ||
| Operating voltage(v) | min | 15 | T＞0%℃ |
| max | 21.9 | ||
| Nominal capacity (Ah) | 302 | 1/3C，100%DOD | |
| Nominal energy (KWh) | 5.834 | 1/3C，100%DOD | |
| Cell Configuration | 1P6S | ||
| End of life residual capacity (Ah) | 241.6 | ||
| Module weight (Kg) | 40.78 | ||
| Maximum continuous charge current (A) | 302 | ||
| Maximum continuous discharge current (A) | 302 | ||
| Maximum pulse discharge current (≤30s)(A) | 604 | ||
| SOC operating range (%) | 10~90 | ||
| Insulation requirements(MΩ) | ≥20 | ||
| Module cooling method | Natural cooling | ||
| Module heating film | No | Or heating film | |
| Shipping capacity (SOC) | ≈30% | SOC is consistency in the same batch | |
| Dimension L (mm) | 555.5 | ||
| Dimension B (mm) | 180 | ||
| Dimension H (mm) | 225 | ||
