Reliable 106Ah Lithium Iron Phosphate (LFP) cell with high energy density, long cycle life (≥1,500 cycles), and excellent safety. Lifepo4 cell operates from -20°C to 60°C, ideal for ESS, EVs, and renewable energy. CE & UN38.3 certified.
.png "lfp106_(1).png")
| Item | Specification | |
| Dimension (Welding terminal) | 47.8±0.5mm *173.9±0.5mm *132.6±0.6mm | |
| Weight | 2.10±0.11kg | |
| Min. capacity | 106Ah (1C) @ 25℃ | |
| Min. energy | 339.2Wh | |
| SOC window | 10 ~ 90% | |
| Terminal | Welding terminal | |
| Impedance（1kHz） | ≦0.4mΩ | |
| Voltage | Max. | 3.65 V |
| Nominal | 3.2 V | |
| Min. | 2.5V (T＞0℃） 2.0V (T≤0℃) | |
| Current | Maximum continuous charge | 106A |
| Maximum continuous discharge | 106A | |
| Energy density | Gravimetric | 161Wh/kg |
| Volumetric | 307Wh/L | |
| Temp. Condition | Operation (Charge) | 0 ~ 55℃ |
| Operation (Discharge) | -20 ~ 55℃ | |
| Cycle Life | 1C/1C, 80% DOD 25℃ | 1500 cycles |
| Abuse test | Overcharge, Over-discharge, Short, Heat | GB/T 31485-2015 |
.png "lfp106_(3).png")
.png "lfp106_(4).png")
.png "lfp106_(5).png")
.png "lfp106_(6).png")
.png "lfp106_(7).png")
.png "lfp106_(8).png")
.png "lfp106_(9).png")
