Container energy storage system offers a flexible and mobile solution for storing electricity, characterized by its modular design and ease of transportation.
.png "200ah14p384s_(1).png")
| Item | Parameters | |
| Battery Pack | Nominal Voltage (V) | 153.6 |
| Capacity (kWh) | 30.72 | |
| Cell Type | 3.2V/200Ah | |
| Cell Configuration | 1P48S | |
| Battery Cluster | Nominal Voltage (V) | 1228.8 |
| Capacity (kWh) | 245.76 | |
| Pack Configuration | 1P48S-8S | |
| SSXXXX02-1228.8V2800A（200AH14P384S） | Nominal Voltage (V) | 1228.8 |
| Capacity (MWh) | 3.44 | |
| Cluster Configuration | 1P48S-8S-14P | |
| Rated Power | 1P | |
| Fire Protection System | PACK-rated perfluorohexanone fire extinguishing system + water sprinkler | |
| Weight | ≤38T | |
| Waterproof Level | IP55 | |
| Operating Humidity | 0~95% (non-condensing) | |
| Operating Temperature Range | -30～55℃ | |
| Cycle Life | 6000 times 1Cycle/day (@25±3°C, 0.5P) 90% DOD EOL 80%SOH | |
| Cooling Method | Liquid Cooling | |
| Dimension L×W×H (mm) | L6900*W2600*H3000 | |
| Communication methods | MODBUS RTU/TCP、IEC104、IEC61850 | |
.png "200ah14p384s_(3).png")
.png "200ah14p384s_(4).png")
.png "200ah14p384s_(5).png")
.png "200ah14p384s_(6).png")
.png "200ah14p384s_(7).png")
.png "200ah14p384s_(8).png")
.png "200ah14p384s_(9).png")
.png "200ah14p384s_(11).png")
.png "200ah14p384s_(10).png")
