PC36XX23-153.6V230A (230AH1P48S) features a 1P48S configuration with a rated energy of 35.33kwh and a rated voltage of 153.6 V. Whether it's a reliable source of energy for an electric vehicle or a powerful standby system for an industrial application, this Li-ion battery is up to the task.
Equipped with advanced safety features, such as protection against short circuits, overcharging, and overheating, this lithium battery pack ensures the utmost security for your valuable equipment, enabling worry-free operation.
.png "PC36XX23-153_(1).png")
| No. | Items | EP-LFP 230h STADARD PACK | Note | |
| PC36XX23-153.6V230A | ||||
| 230AH1P48S | ||||
| 1 | Nominal voltage(V) | 153.6 | ||
| 2 | Operating voltage(V) | min | 120 | |
| 3 | max | 175.2 | ||
| 4 | Group mode | 1P48S | ||
| 5 | Nominal energy（KWh ） | 35.33 | 25±2℃ | |
| 6 | Nominal capacity(Ah) | 230 | 25±2℃ | |
| 7 | Maximum continuous charge current（A） | 230 | ||
| 8 | Maximum continuous discharge current（A） | 230 | ||
| 9 | Maximum pulse discharge current（≤30s）（A） | 460 | ||
| 10 | Shipping consistency（mv） | 30 | Voltage difference between cell ＜30mV | |
| 11 | Humidity range | ≤65% | ||
| 12 | Storage temperature(℃) | -30～60℃ | ||
| 13 | SOC operating range（%） | 20~100 | ||
| 14 | Insulation requirements(MΩ) | ≥20 | 500V DC，High voltage output to battery shell, at the normal temperature and humidity | |
| 15 | cooling method | Liquid cooling | ||
| 16 | Shipping capacity | ≈30% | SOC is consistency in the same batch | |
| 17 | Dimension L (mm) | 1065 | ||
| Dimension B (mm) | 630 | |||
| Dimension H (mm) | 245 | |||
.png "PC36XX23-153_(3).png")
.png "PC36XX23-153_(4).png")
.png "PC36XX23-153_(5).png")
.png "PC36XX23-153_(6).png")
.png "PC36XX23-153_(7).png")
.png "PC36XX23-153_(9).png")
.png "PC36XX23-153_(10).png")
.png "PC36XX23-153_(11).png")
.png "PC36XX23-153_(12).png")
.png "PC36XX23-153_(13).png")
