This PC020509-173.88V277A(277Ah1P54S) Pack is a high-performance, lithium-ion marine DNV battery pack that offers reliable and efficient power storage. It is designed to provide consistent power over a wide temperature range and is resistant to shock and vibration. It is also DNV certified with reliable performance.
| Attribute | 277Ah |
| Chemistry | LiFePO4 |
| System Voltage nominal | 77-772V |
| System Capacity | 277Ah |
| system Energy | 21.4kWh-214.1kWh |
| System Continous charge current | 277A |
| System Continous discharge current | 277A |
| Temperature range charge | 0℃-55℃ |
| Temperature range discharge | -20°℃-55℃ |
| Heating System | PTC Heater inside each |
| Ingress protection Pack | IP67 |
| Ingress protection PDU | IP67 |
| Communication protocoll | CAN 2.0A/B, SAEJ1939 |
| Pack size | Type -L-S-M-LFP-277 |
| Capacity [Ah] | 277Ah |
| Voltage [V] | 173.88 |
| Cell config. | 54 |
| Modul config. | 6x (1p9s) |
| Energy [kWh] | 47.9 |
| Weight [kg] | 355.9 |
| Width [mm] | 630 |
| Heigth [mm] | 240 |
| Length [mm] | 1697 |
| Fuse | 630A |
